Fabtech K2038DL 10" 4 Link Lift Kit w/ Dirt Logic SS 4.0 Coilovers & Rear Dirt Logic SS Shocks

7.00In stock
  • Brand: Fabtech
  • |
  • SKU: FAB-K2038DL
  • |
  • Part Number: K2038DL

2008-2010 Ford F-250 Super Duty 4WD

$7,316.96
- +
Your discount may still be available. Contact us in Live Chat
  • Lowest Prices
    Price match guarantee
  • In-House Experts
    We know our products
  • Factory Authorized
    Install Center
  • Guaranteed Fitment
    Always the correct part
  • Free Shipping
    In the continental US
  • International Shipping?
    Get a Quote
Have a Question?
702-267-6100
Talk to a Specialist Now

Product Details

At the top of our Super Duty line is our famous 4 Link System that provides unsurpassed articulation and wheel travel. Large 2" OD heavy wall links feature race style 1" Uniballs for superior strength. Thick 1/4" steel brackets secure the 4 Links to the frame without cutting or welding. This 4 Link system includes our front Dirt Logic 4.0 Coilover conversion. The system also includes Billet Sway bar links, Trac Bar relocation bracket, Pitman Arm and more. Rear lift is replacement leaf springs and block & u-bolt kit.

Product Questions

Ask A Question

Fitment

YearsDriveMakeModel
2008-20104WDFordF-250 Super Duty

Features

  • 2" OD Heavy Wall Links
  • Fabtech Heavy Duty 5 Ton Joints
  • Front Dirt Logic 4.0 Coilovers
  • Trac Bar Relocation Bracket
  • Sway Bar Drop Brackets
  • Pitman Arm
  • Rear Leaf Springs
  • Rear Block & U-bolt Kit

Components

  • Component Box 1
  • Component Box 2
  • Component Box 3
  • Front Dirt Logic 4.0 Coilover
  • Rear Block & Leaf Spring Kit
  • Rear Dirt Logic 2.25 Non Resi

Front Dirt Logic 4.0 Stainless Steel Coilovers

The Dirt Logic 4.0 provides the ultimate in hardcore offroad dampening capacity with superior highway comfort in a big package. This massive high end shock is designed for full size vehicles that required the biggest and best Coilover shock in a bolt on configuration. Nothing else comes close.

  • 4.0" OD Stainless Steel Body
  • 3 5/8" OD Billet Aluminum Piston
  • 1.25" NitroSteel® Black Piston Rod
  • Adjustable Coilover Construction
  • 3/4" Spherical Ball Mounting Ends
  • Non Resi, 4.0" OD Piggyback Resi and 4.0" OD Remote Resi

Rear Dirt Logic 2.25 Stainless Steel Non Resi

Dirt Logic 2.25's are designed to replace factory shocks with a larger, more robust configuration. The 2.25 size is what separates it from other replacement take apart shocks for a superior ride, both on and off road. Shocks are pretuned for each Fabtech suspension, accounting for larger tires, providing the finest all around damping.

  • 2.25" OD Stainless Steel Body
  • 2.0" OD Billet Aluminum Piston
  • 7/8" NitroSteel® Black Piston Rod
  • Polyurethane Mounting Ends
  • Optional 2.25" OD Aluminum Reservoir w/-6 Stainless Steel O-ring Hose

Quick Specs

  • Tire Size - 40/12.50R17 Wheel Size - 17x9 w/ 4 5/8in BS w/minor trimming
  • Tire Size - 40/13.50R20 Wheel Size - 20x10 w/ 4 1/2in BS w/minor trimming

Important Notes

  • 27. Front drive shaft modification may be required to clear exhaust on gas motor.
  • 29. Rear leaf springs may reduce load carrying capacity.
  • ATTN State of California Consumers warning: Cancer and Reproductive Harm www.p65warning.ca.gov
