Fabtech K2032DL 6" 4 Link Lift Kit w/ Dirt Logic SS 4.0 Coilovers & Rear Dirt Logic SS Shocks

5.00In stock
  • Brand: Fabtech
  • |
  • SKU: FAB-K2032DL
  • |
  • Part Number: K2032DL

2008-2010 Ford F-250 Super Duty 4WD

$5,612.37
- +
Your discount may still be available. Contact us in Live Chat
  • Lowest Prices
    Price match guarantee
  • In-House Experts
    We know our products
  • Factory Authorized
    Install Center
  • Guaranteed Fitment
    Always the correct part
  • Free Shipping
    In the continental US
  • International Shipping?
    Get a Quote
Have a Question?
702-267-6100
Talk to a Specialist Now

Product Details

At the top of our Super Duty line is our famous 4 Link System that provides unsurpassed articulation and wheel travel. Large 2" OD heavy wall links feature race style 1" Uniballs for superior strength. Thick 1/4" steel brackets secure the 4 Links to the frame without cutting or welding. This 4 Link system includes our front Dirt Logic 4.0 Coilover conversion. The system also includes Billet Sway bar links, Trac Bar relocation bracket, Pitman Arm and more. Rear lift is a block & u-bolt kit.

Product Questions

Ask A Question

Fitment

YearsDriveMakeModel
2008-20104WDFordF-250 Super Duty

Features

  • 2" OD Heavy Wall Links
  • Fabtech Heavy Duty 5 Ton Joints
  • Front Dirt Logic 4.0 Coilovers
  • Trac Bar Relocation Bracket
  • Sway Bar Drop Brackets
  • Pitman Arm
  • Rear Block & U-bolt Kit

Components

  • Component Box 1
  • Component Box 2
  • Component Box 3
  • Front Dirt Logic 4.0 Coilover
  • Rear Block Kit
  • Rear Dirt Logic 2.25 Non Resi

Front Dirt Logic 4.0 Stainless Steel Coilovers

The Dirt Logic 4.0 provides the ultimate in hardcore offroad dampening capacity with superior highway comfort in a big package. This massive high end shock is designed for full size vehicles that required the biggest and best Coilover shock in a bolt on configuration. Nothing else comes close.

  • 4.0" OD Stainless Steel Body
  • 3 5/8" OD Billet Aluminum Piston
  • 1.25" NitroSteel® Black Piston Rod
  • Adjustable Coilover Construction
  • 3/4" Spherical Ball Mounting Ends
  • Non Resi, 4.0" OD Piggyback Resi and 4.0" OD Remote Resi

Rear Dirt Logic 2.25 Stainless Steel Non Resi

Dirt Logic 2.25's are designed to replace factory shocks with a larger, more robust configuration. The 2.25 size is what separates it from other replacement take apart shocks for a superior ride, both on and off road. Shocks are pretuned for each Fabtech suspension, accounting for larger tires, providing the finest all around damping.

  • 2.25" OD Stainless Steel Body
  • 2.0" OD Billet Aluminum Piston
  • 7/8" NitroSteel® Black Piston Rod
  • Polyurethane Mounting Ends
  • Optional 2.25" OD Aluminum Reservoir w/-6 Stainless Steel O-ring Hose

Quick Specs

  • Tire Size - 315/70R17 Wheel Size - 17x8 w/ 4 1/2in BS w/minor trimming
  • Tire Size - 325/65R18 Wheel Size - 18x9.5 w/ 4 3/4in BS w/minor trimming
  • Tire Size - 35/12.50R20 Wheel Size - 20x10 w/ 5in BS w/minor trimming

Important Notes

  • 27. Front drive shaft modification may be required to clear exhaust on gas motors.
