Fabtech K1009/K1009M 6" Performance Lift Kit w/ Rear Standard Shocks

Rated /5 based on 0 customer reviews
2.00In stock
  • Brand: Fabtech
  • |
  • SKU: FAB-K1009/K1009M
  • |
  • Part Number: K1009/K1009M

2000-06 GM K1500

- +
Your discount may still be available. Contact us in Live Chat
  • Lowest Prices
    Price match guarantee
  • In-House Experts
    We know our products
  • Factory Authorized
    Install Center
  • Guaranteed Fitment
    Always the correct part
  • Free Shipping
    In the continental US
  • International Shipping?
    Get a Quote
Have a Question?
Talk to a Specialist Now

Product Details

Lift is accomplished via one-piece ductile iron drop down steering knuckles attaching to heavy duty 1/4" thick, high arched lower control arm crossmembers. Fabtech's combination of steering knuckles and high arched crossmembers provides superior ground clearance for the true offroader. The front differential is relocated with a cradle style bracket using bushings at just the proper angle to allow the use of the factory front driveshaft, without vibration on AutoTrac models. Solid steel billet sway bar end links with urethane bushings retain the factory front sway bar angle. The stock upper control arms and steering centerlink are retained in the factory position and do not have to be removed for installation. The front suspension is completed with crossmember impact struts and torsion bar drop down brackets.

Product Questions

Ask A Question


2000-20064WDChevroletK 1500 SUV/SUT
2000-20064WDGMCK 1500 SUV


  • Allows use of stock tires & wheels
  • No driveshaft change required for AutoTrac models
  • Allows use of Standard, Load Leveling and AutoRide shocks
  • High arch 1/4" thick crossmembers
  • Includes 1/4" thick steel differential skid plate
  • Solid steel billet sway bar end links
  • Tubular Impact Struts included
  • Increased caster for more control with oversized tires

Rear System Features & Bene

  • Replacement extended length coil springs
  • Trac Bar drop bracket
  • Shock mount relocation brackets
  • Extended sway bar end links


  • Component Box 1
  • Component Box 2
  • Rear Coil Kit
  • Front Performance Shocks

Performance Shocks

Fabtech Performance Shocks have been designed to work in conjunction with each of our suspension systems, resulting in superior ride control. Features include high velocity 9-stage valving for excellent dampening capabilities and a closed cell insert to reduce shock fade at high speeds.

  • Twin Tube Hydraulic Construction
  • 9/16" Hardened Chrome Piston Rod
  • 1 3/8" OD Piston
  • Closed Cell Foam insert
  • High Flow 9 Stage Valving
